TECNA 4642N Rocker Arm Spot Welder

20 kVA | Foot-Operated | Single-Phase AC

WSI Stock / Serial #: TECNA-4642N

The TECNA 4642N is a 20 kVA, foot-operated, single-phase AC rocker arm spot welder. The 4642N features adjustable arms, electrode stroke, and force. The chrome-copper electrode holders are designed for straight and angled fittings. Furthermore, the standard TE101 controls are mounted on the front of the machine, allowing the operator to view data while welding.

  • Model: TECNA 4642N
  • Power @ 50% duty cycle:  20 kVA
  • Power supply:  Single-phase AC
  • Max. weld current: 9,600 amps
  • Max. weld force: 337 lbs.
  • Max. electrode throat depth: 27.56 in.
  • Max. projection plate throat depth: —

WSI maintains an inventory of new and used resistance welding equipment, including TECNA rocker arm spot welders at our Warrensville Heights, Ohio location for quick shipment and delivery. Contact our knowledgeable sales team at 844-WSI-WELD or 216-475-5629 for immediate assistance.

QUOTE REQUESTFeaturesSpecifications

Please submit the following form to request additional information.

Enter “TECNA-4642N” on the following quote request form.

If you have any questions, please call 844-WSI-WELD or 216-475-5629 and ask to speak with a WSI Engineer.

    Contact Information
    * Full Name:
    * Company Name:
    City:
    State:
    Postal Code / Zip:
    Country:
    * Phone:
    * Email:
    * Preferred way to be contacted:
    Equipment Needs
    Equipment Request:
    TECNA Model / Serial Number:
    * Tell us about your application (what are you welding?): Send us a photo of your parts:

    * Required


    If you experience any issues submitting this form, please give us a call at 844-WSI-WELD or 216-475-5629.

    • TE101 weld controls, mounted on the front of the machine, allow the operator to view data while welding.
    • Water-cooled transformer, arms, and electrodes. Epoxy resin-coated transformer for maximum protection.
    • Adjustable electrode stroke enables access to a greater range of parts.
    • Chromium-copper electrode holders are designed for long life and heavy-duty service. May be mounted at 12° and 90° positions in the arm. Optional Universal-Style arms are available exclusively from WSI for 1” diameter electrode holders, and for mounting the electrode holders at 30° and 90°.
    • Adjustable throat depth enables maximum flexibility.
    • Ergonomic frame for long-term operation in production environments.
    • WSI Exclusive Standard Low-Profile Lower Holder enables accessing parts as small as 3″ in diameter.
    • Single foot pedal

    *May be supplied capable of operating on other voltages/frequencies. Please ask for details.
